SegNet

Nodal Design and Cable Routing

Key Functions

1 Build and manage accurate, cable-specific records of equipment connection points and length tracking termination details
2 Enable both automated and manual cable routing based on predefined routes, segment capacities, and cable type compatibilities
3 Connect linking cables to specific equipment tags to allow full traceability from equipment endpoints
4 Make data available across multiple engineering disciplines when integrated with EIS database
5 Store information such as cable types, routing paths, and installation status in a second cloud database
6 Calculate the most efficient routing path and alert users of potential segment overload
7 Track and update installation status as they move along different project phase
8 Register equipment tags with associated nodes and location details
9 Provide accurate visualisations of cable networks

What is SegNet?

SegNet offers user-friendly 3D visualization of cable networks, nodes, and routing paths. Streamline cable management with optimised routing automation, customisable display preferences, and seamless CABSYS integration. Flexible and efficient, SegNet is designed to accommodate changes in the project scope and future maintenance updates.

MIMS_Module-09wide

Key Functions

Node and Segment Management

Edit, configure, stack, and search nodes and segments.

Automated Cable Routing

Find shortest paths while ensuring compliance with physical limitations.

3D CAD Integration

Auto-generate customizable 3D diagrams with multiple view options.

Batch Processing

Auto-generate customizable 3D diagrams with multiple view options.

Cable Routing and Visualization

Route cables and verify paths with color-coded visual displays.

Integration with CABSYS

Gain immediate access to the latest cable and network data.

3D Network Visualization

Auto-generate customizable 3D diagrams with multiple view options.

MIMS_Module-01wide

SegNet Benefits

1 EnhancedData Accuracy
2 User-friendly Interface
3 Network Visualization
4 Versatile Network Design
5 Adaptability forproject-specific needs
6 User-friendly interface designed for engineers
